An automatic tray-wrapper RFQ starts with the machine. “High cling, 450 mm” is not enough to confirm that a roll will load, track, cut and wrap.
Copy this equipment block
| Field | Buyer entry |
|---|---|
| Machine | Manufacturer, full model, manual/drawing revision |
| Film station | Shaft/holder, brake or tension system, film path |
| Roll envelope | Web width, core ID/OD/length, maximum roll OD and weight |
| Winding | Direction, film side/orientation, splice allowance |
| Operation | Tray min/max, speed, settings, stops and changeovers |
| Pack result | Defined folds, cut/seal, appearance and inspection time |
Use a three-gate trial
- Desk fit: compare proposed roll drawing with the machine limits.
- Load and jog: confirm clearance, direction and tracking.
- Representative run: log startup, steady operation, stop/restart and the difficult tray formats.
Keep settings fixed when comparing films. Retain failed packs and identify the roll and machine count.
Lock the approved configuration
The order should reference the film SKU, roll drawing, machine, settings window and trial record. Use the core-fit guide for loaded-roll checks. YIYUAN's product page provides starting dimensions only; machine compatibility must come from this completed sheet and the trial.
